DK7740D
Metal 3D Printing Platform
Technical Data
Specifications:
| XY Axis Travel: | 500 × 400 mm |
| Worktable Size: | 785 × 500 mm |
| Cutting Thickness: | Max. 500 mm |
| Taper Cutting: | ± 3°(Thickness ≤ 100 mm) |
| Loading Weight: | Max. 500 kg |
| Machine Weight: | 1700 kg |
Processing Parameters:
| Cutting Precision: | 0.015 mm |
| Machining Efficiency: | 150 mm2/min |
| Work Current: | Max. 6 A |
| Work Power: | 3-phase 380 V±5%, 50 Hz |
Configurations:
| XY Axis Control: | Step control |
| Z Axis Elevation Control: | Manual |
| Screw and Guide Rail: | Precision ball screw/ Precision linear guide rail |
| Wire Type: | Molybdenum wire |
| Wire Feeding System: | Converter control |
| Hand Cranked Pulse: | Optional |
| Working Liquid: | Water-based liquid |
| Working Liquid Filter System: | Multiple filtration |
| Cabinet: | BMW3000 |
| Machine body: | Integrated machine body, Meehanite cast iron (HT250) |
